12VDC / 24VDC Pure Sine Wave UPS LCD 5000VA / 3500W computer uninterruptible power supply

12VDC / 24VDC Pure Sine Wave UPS LCD 5000VA / 3500W computer uninterruptible power supply
12VDC / 24VDC Pure Sine Wave UPS LCD 5000VA / 3500W computer uninterruptible power supply

Large Image :  12VDC / 24VDC Pure Sine Wave UPS LCD 5000VA / 3500W computer uninterruptible power supply

Product Details:
Place of Origin: China
Brand Name: LSG
Certification: CE,FCC,ISO9001
Model Number: LSG
Phase: Single Phase
Protection: Overcurrent
Output Voltage: 220V /110V
Type: Line Interactive
Application: Computer
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Get Latest Price
Packaging Details: 1pc/carton
Delivery Time: 30 working days
Payment Terms: L/C,T/T,Paypal
Supply Ability: 10000pcs/month
Detailed Product Description
High Light:

ups pure sine wave

,

double conversion ups

12VDC / 24VDC Pure Sine Wave UPS LCD 5000VA / 3500W computer uninterruptible power supply



Specifications


1.TX-T Series Sine Wave UPS LCD 5000VA
2 LCD display
3 pure sinewave output
4 good price




TX-T Series Sine Wave UPS LCD 5000VA



specification :



MODEL   TX-T500M/L TX-T1000M/L TX-T2000M/L TX-T3000M/L TX-T5000M/L
CAPACITY W 500VA(350W) 1KVA(700W) 2KVA(1400W) 3KVA(2100W) 5KVA/3500W
INPUT Phase Single
Voltage 100/110/127/220/230(+25%,-25%)
Frequency 60/50+/-10%
OUTPUT Phase Single
Voltage range(VAC) 100/110/127/220/230+/-5%
Frequency Commercial power supply shared frequency with the commercial inversion state:60/50+/-0.5
Waveform Sine wave
Power Factor P.F. 0.7 0.7 0.7
BATTERY Battery Type & Number 12V/7AH x 1pcs 12V/7AHX2PCS 12V/17AH x 2pcs 12v/17AHx2pcs  12v/17AHx4pcs
DC Voltage 12VDC/24VDC 24VDC 48VDC
Back up Time Standard model: (halfload)>/=8min
Recharge current Long back up model: 15A max, standard model: 3A max
TRANSFER TIME Typical Typical: 5ms (Including detection time)
Display LCD/LED Optional
PROTECTION Full Protection Discharge, overcharge, and overload protection
PHYSICAL Dimension, DXWXH (mm) 375*130*190 452*192*338 452*192*338
Out packing Size, DXWXH (mm) 495*490*320(2pcs/ctn) 584*335*495(1pcs/ctn) 584*335*495(1pcs/ctn)
Net Weight (kgs) 12/7(L) 23/15.6(L) 27/23.7(L) 33.7
ENVIRONMENT Operating Environment 0~40 Degrees Centigrade, 0~90% relative humidity (non-condensing)
Noise Level Less than 40dB
INTERFACE Smart RS-232 Support Windows family, Linux, Compaq True64,
USB Option N / A
