Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp

Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp
Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp

Large Image :  Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp

Product Details:
Place of Origin: China
Brand Name: ZOCEN
Certification: CE,CQC,IEC,TUV,CEC,MCS,CHUBB, ISO9001
Model Number: ZCSSL-30W
Payment & Shipping Terms:
Minimum Order Quantity: 10000pcs
Price: negotiation
Delivery Time: 20 days
Payment Terms: Ex works
Supply Ability: 1, 500, 000PCS/month
Detailed Product Description
High Light:

led solar garden lights

,

solar powered sidewalk lights

Pure White Solar Powered Street Lighting , IP68 30w Led Street Lamp



1> Quick details

  • Light Source: LED
  • Item Type: Street Lights
  • LED Light Source: 30W
  • Input Voltage(V): 12
  • Lamp Power(W): 30
  • Lamp Luminous Flux(lm): 1000
  • Lamp Luminous Efficiency(lm/w): 100
  • CRI (Ra>): 80
  • Color Temperature(CCT): Pure White
  • Working Temperature(℃): -40 - 60
  • Working Lifetime(Hour): 60000
  • Lamp Body Material: Aluminum
  • IP Rating: IP65
  • Certification: BV, CE
  • Warranty(Year): 1
  • Lampshade Material: Toughened Glass
  • Power Supply: DC
  • Lighting Bulbs & Tube: Energy Saving
  • Application: street
  • led power: 30W
  • controller: phocos IP68
  • light source: 30W LED lighting
  • pole: steel pole Q235
  • Item type: solar power street light with 30w 50w led street lamp



2> Descriptions:



solar power street light with 30w 50w led street lamp outdoor lighting
Name Specification Quantity Parameter
Solar panel 120W/12V 1 piece

Polycrystalline, 156x156mm,36 piece.

Size:1490x670x35 with 90cm wires,MC4 Connector. and Weight:12KG

Warranty: More than 90% output power in 10 years .and more than 80% output power in 25 years.

The product have passed TUV, IEC, MCS etc certificate.

Light source



LED30W/12V

1 piece

Single Integrated Power LED(30W),Woking Voltage DC12V,General luminous:3000lm,LED Luminous Efficiency:100lm/W,Center illuminance:14lx,Ra>80,Color temperature:2700-7000,Protection Grade :IP65,Working life >50000, It can woke more than 10 years in accordance with 12 hours a day.

Lamp shade is Die-casting molded with aluminum alloy,and its face is UV-resistant and corrosion resistant .

No bad glare; No Strobe; Start without delay .Low maintenance cost .

Controller 10A 1 piece PHOCOS CIS Series,12V/24VAutomatic identification , light control and time control,Protection Grade IP68
Battery 12V/120AH 1 piece Gel Battery that dedicated to solar energy. It can use recurrent more than 400 times in 100% discharge cases For the solar energy street lamp that in simple circulatory system. And its advantage is that :the small self -discharge rate ,the better deep discharge, Top charge acceptance, large capacity,strong start in low ,the good shock resistant and Anti-temperature charge Production
Size: 483x170x240mm,Weight :44.5K
Pole and other steel fitting 6M Set Best steel Q235 or Q345;hot dip galvanized and paint coated .
iron plate is rolled into type for one time .
Flange plate :350x350x20mm
Solar panel bracket and 4# or 5# Angle iron,50x5mm and 100x100mm Flat iron. Square tube is assembled by bolt ,any section is made with mold. With high efficiency and precision , standardized parts can replace each other and the same time increase the packing quantity and reduce transport cost .
Wires harness -- 1 piece

With the special connector ,standardization,substitutability ,high installing efficiency,saving cost .

Wire harness can be designed according to different lamp type .

others Baseplate 20 steel rod ,standard component and so on
Conditions Voltage of system: 12V,working time: 10 hours ,Best work temperature -20degree-50degree
Packing Quantity 40set/20FCL



3> Our Services



  • What we offer
  1. Quality solar systems are offered at competitive pricing
  2. Excellent sales and customer service skills
  3. We are not a pushy sales team , we believe in honesty and integrity & doing RIGHT by our customers
  4. Before and after sales service



  • Warranty

ZOCEN SOLAR Guarantees the purchaser for the period of two (2) years for the whole lighting system.



  • Installation
  1. ZOCEN SOLAR offers detailed instructions and videos for installation.
  2. Besides, We could provide onsite installation training for 7 to 15 days accordingly.



4> About Zocen Solar







Jieyang Zocen Group Co., Ltd(Also short for" Zocen Solar) is one of the leading manufacturer in solar cells, solar panels and solar power system development, production, sales and service. The company owns high level quality management system and modern working environment.




Totally different from other crystalline solar cell in China, Zocen solar focus on N type crystalline solar cell, which enjoy high conversion efficiency and long lifespan. Due to its special and difficult production process, we are the only 2 manufacurer of this crystalline solar type in China and the largest solar cell manufacturer in Guangdong province.

All of our customers had made remarkable progress and established long-term business relationships with ZOCNE SOLAR in the pass. And we firmly believe that there will be more promising in the following couple of years based on our excellent R&D, stringent QC and good service with Super high quality and new product.
