High Efficiency IP68 50W Solar Powered Sidewalk Lights With SONCAP Certificated

LED: 50W

Lamp Body: High-Pressure Die-Casting Aluminum. Corrosion Resistant

LED Power………………… ………… ..50W

LED Lighting Efficiency…………………6000LM

Body Size…………………..540*296*60mm

Lamp Efficiency……………… ……… …..>92%

Central Illuminance…………………..>30LX

CT………………… ………… ..5000-7000 (White)

Ra……………… ………… ……… ….>75%

Power Factor………………… ……… ..>0.95

IP……………… ………… …. ……… .65

Working Temperature……………-40°C---+60°C

Lifespan…………………. ……… .>50000 Hours

G.Weight………………… ……… .5.5KG

Solar Gelled Battery

120Ah

Nominal Voltage ………… ……… ………12V

Number of cell ……………………………..... 6

Design Life ………………………………… 5-8 years

10 hour rate(12.0A,10.5V) ………………..120Ah

Fully Charged battery 77°F(25°C) ………….4mΩ

Discharge ……………………. ……… . -20~60°C

Charge …………………………….. …… .. -10~60°C

Storage ……………………………………… -20~60°C

Size:………………………………… 406*172*210mm

Weight: ………………………………………32.5Kgs.

Solar Panel: 100W

Adding Aluminum Frame, Tempered Glass.

A-class.

Silicon Type………………………………Poly

Size………………….. ……… 990*704*35mm

Cells…………………….. ……… .........60

N Weight…………………….. ……… 8.5KG

Vmp…………………….. ……… ……17.2V

Imp…………………….. ……… …….5.81A

Voc…………………….. ……… ……21.6V

Isc…………………….. ……… ……… 4.63A
Efficiency: ……………………. ……… ≥15.5%
FF(%)…………………….. ……… .70-72%

Operating temperature………. …… -40°C to +80°C

GI Pole System

8Metre

Pole Height…………………………………8M
Material……………………………………..Q235,

Top Diameter……………………………….80mm

Bottom Diameter…………………………..185mm

Pole Thickness……………………………..3.5mm

Painting:……………………………..Wanted Colour
8M Height Pole,Steel, Q235,

Hot-Dip Galvanized. Plastic Coated, Rust Proof,

With Arm, Bracket, Flange, Fittings, Cable, Etc

Resistant to Wind: ≥150KM/H

Solar Controller

10A/24V Controller

Intelligent Micro-computer Controller

Automatic Light Control and Time Control System

IP Level …………………………….IP68

Size………………………………..81*60*22mm

N. Weight………………………….0.16KG
Working Temperature:-20°C to 60°C

Over-charging/discharging Protection

Reverse-connection Protection

Switch on Automatically with Light Sensor;

Switch off after 11-12 Hrs later.

Battery Box

Bury under ground

Material: PVC material; with PVC cable tube.

Sealing: Sealing strips,

Waterproof and Heat-dissipative

Cables From controller to Lamp to

Solar panel, solar batteries, controller.

Armoured cable, include eather-protective cable glands
