3KW Domestic Off Grid Solar Panel Systems For Solar Power Generator

Large Image : 3KW Domestic Off Grid Solar Panel Systems For Solar Power Generator

Product Details:

Place of Origin:	China
Brand Name:	CESC
Certification:	CE/CSA/TUV
Model Number:	CESC-KGP3000

Payment & Shipping Terms:

Minimum Order Quantity:	50 Units
Price:	negotiation
Packaging Details:	Packaging in carton or wooden case
Delivery Time:	10 working days after received your payment
Payment Terms:	T/T or LC at sight
Supply Ability:	3,0000pcs per month

Contact Now

Detailed Product Description

Product Name:	3KW Off-grid Home Solar Power System	Application:	Solar Generator
Quantity Of Panel:	10 Pcs Or Optional	Quantity Of Inverter:	1
Power Of Inverter:	3KW	Standard:	CE/CSA/TUV
Type:	Home Solar Power System
High Light:	off grid living solar power system , off grid home solar power system

3KW Off-grid home Solar Power System Intelligent Power Generator

Specifications

3kw home solar power systems
1. High efficiency
2. Total system 5 years warranty
3. Solar power system
4. ISO/CE/UL/TUV

ITEM	SPECIFICATION:
SOLAR PANEL	TYPE NO:		P7Y-300
	QTY:		10pcs
	CONNECT ARRAY:		2pcs in series, 5 series in parallel
	SPEC:	CELLS:	156mm polysilicon cells*72
		Pm(Wp):	300W
		Vm(V):	36V
		Im(A):	8.33A
		Voc(V):	44.8V
		Isc(A):	8.73A
		size(MM):	195699245MM
		N.W(KG):	22.5KG
SOLAR BRACKET	Material:		Galvanized steel
	SPEC:		2*5,suit for solar panels array
	Install place:		ground or flat roof
PV COMBINER BOX	TYPE NO:		PVX5-1
	SPEC:	channels:	5in, 1out
		Material:	plastic
		Defence function:	yes
		Communication:	no
POWER BOX	TYPE NO:		CESC-KGP3000
	CONTROLLER:	Controller Mode:	PWM
		Solar panel input range:	DC60V-DC100V
		Rated voltage of solar input:	DC72V
		Floating charge voltage:	58V
		Charging voltage:	48V DC
		Charging current:	60A
		Efficiency:	96% (Max)
	INVERTER:	Rated Output Power:	3KW
		Peak power:	200% * 1s
		Output vltage:	220V50HZ/110V60HZ
		Working Efficiency:	>83%
		Output Wave:	Pure Sine Wave(THD≤5%)
		Grid power input:	220V50HZ/110V60HZ
		Switching Time:	≤4 ms (between grid and inverter)
		Protection Functions:	DC over-voltage protection/over-voltage self-revcovery
			DC low-voltage protection/low-voltage self-revcovery
			Overheat/short-current/overload protection
		Features:	AVR Functions:AC145V-275V(input), AC198V-242V (output)

			batteries can be charged by Grid and automatic supply power when Grid cut off

	Size:		490mm×235mm×485mm (With wheels)
	N.W:		42.6kg
BATTERY	Battery Type:		Maintain-free Lead-acid battery
	Capaticty:		12V/200AH*4 (Max.:9600WH)
	connect array:		4pcs in series
	system voltage:		48V DC
	N.W:		60
BATTERY BRACKET	SPEC:	Material:	steel
		structure:	framework
OTHERS ACCESSORIES	PV CABLE:	SPEC&QTY:	4mm sq with MC4 connectors: 30m
			10mm sq with MC4 connectors: 30m
	POWER CABLE:	SPEC&QTY:	35mm sq, 3m
