Single Phase Online 2 Kva / 1.8Kw 120Vac / 110V UPS Residential Ups Systems

Single Phase Online 2 Kva / 1.8Kw 120Vac / 110V UPS Residential Ups Systems
Single Phase Online 2 Kva / 1.8Kw 120Vac / 110V UPS Residential Ups Systems Single Phase Online 2 Kva / 1.8Kw 120Vac / 110V UPS Residential Ups Systems

Large Image :  Single Phase Online 2 Kva / 1.8Kw 120Vac / 110V UPS Residential Ups Systems

Product Details:
Place of Origin: China
Brand Name: UPSEN
Certification: CE, ISO, RoHS
Model Number: King Star Series 1-3Kva
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Cartons & Wooden Pallet
Delivery Time: 7-15 Days
Payment Terms: T/T, LC, WU, Money Gram etc
Supply Ability: 50,000pcs/Month
Detailed Product Description
Type: Online Output Power Factor: 0.9
Phase: Single Phase Protection: Over Load/Current/Voltage, Short Circuit Etc
Display: Digital LCD Display H.S. Code: 8504402000
Output: 110V/115V/120Vac
High Light:

2000 watt pure sine wave power inverter

,

3 kva online ups



Single Phase Online 2 Kva / 1.8Kw 110V 120Vac UPS Residential Ups Systems

Model: High Frequency Online UPS King Star Series 1-3Kva (1ph in/1ph out)





Application



It’s not only high stable but also with excellent performance.
Perfect Application: Network, data centre, servers and workstations, control system, communication system and office etc.





Key Features



1. Output power factor 0.9,offering more stronger load capability;
2. Online double conversion with DSP control
    With excellent performance and comprehensive protections for load and UPS ;
3. Self-diagnosis when UPS start up
4. Wide input range, support kinds of generator
5. Battery configuration flexible, 1KVA-24/36V, 2Kva-48/72/96V,3Kva-72/96V etc.
6. Cold start(DC power on)
7. ECO function, Economic function (Optional)
8. Compact design and less noise
9. Lightening and Surge protection 1050J
10. Fan speed varies according to load automatically
11. Smart RS232 (USB, Dry contact, SNMP card optional)
12. Manual bypass (optional)





Technical Specification





Model

K1K

K2K

K3K

Capacity

Kva/Kw

1Kva/0.9Kw

2Kva/1.8Kw

3Kva/2.7Kw

Input

Voltage

Low transfer

85Vac± 3% (Ph-N) @100% load , 65Vac± 3% (Ph-N) @50% load

Low back

95Vac(Ph-N) @ 100% load ; 75Vac (Ph-N) @50% load

High transfer

110/120/127Vac:155V± 3%

High back

110/120/127Vac:142Vac± 3%

Frequency range

45-55Hz at 50Hz/55-65Hz at 60Hz(auto-detect)

Phase

1:1phase ,L+N+G

Current THDI

<6%(100%nonlinear load)

Power Factor

≥0.99

Generate Input

Support

breaker

7A

16A

25A

Output

Voltage

110/120/127(1-3Kva)

Power Factor

0.9 (0.8 optional)

Voltage regulation

± 2%

Frequency(Line Model)

46-54Hz at 50Hz/56-64Hz at 60Hz

Frequency(Battery Mode)

50/60Hz ± 0.02Hz

Current Crest Ratio

3:01

Harmonic Distortion

≤3% THD(Liner Load)

≤5% THD(Non-Liner Load)

Output waveform

Pure Sine wave

Outlet

Sockets(Optional)

Terminals

Overload Capacity

105%<load<125% for 1 mins ,125%<load<150% for30sec

Efficiency

AC Mode

Full Load≥89%

Battery Mode

Full Load≥86%

ECO Mode

Full Load≥95%

Battery

Number of Battery Per Set

2-3

2004-6-8

2004-6-8

Battery Type

Sealed, lead-acid, maintenance-free

standard model: 12V/7AH OR9AH inbuilt

long run model: battery external, capacity optional

Back Time

Standard unit:

Standard unit:

Standard unit:

5-12mins;

8-18mins;

5-12mins;

Long-run unit:

Long-run unit:

Long-run unit:

depends on external battery

depends on external battery

depends on external battery

Recharge Time(to 90%)

5 Hours

5 Hours

5 Hours

Charge Current(standard unit)

1.0A

1.0A

1.0A

Charge Current (long run unit)

7.0A

7.0A

7.0A

Rated Battery Voltage

24/36vdc

48/72/96vdc

48/72/96vdc

Protect

Over-Voltage/Over-current/Low-voltage

Battery Socket

Anderson like PowerPole Modular Connectors

Transfer Time

Mains←→Battery

0ms

Mains←→Bypass

0ms

Optional Features

Economic Mode(ECO Mode)

Support

Indicator

LCD Version (with LED)

Load/Battery/Input/Output/Operating Mode Information etc.

Audible Alarm

Battery Mode

Sounding every 4 seconds

Low Frequency

Sounding every second

Overload

Sounding twice every second

Fault

Continuously Sounding

Physical

Unit Dimension (D*W *H)mm

420*144*215

475*191*340

475*191*340

Packing Dimension              (D*W *H)mm

524*258*334

557*286*435

557*286*435

Standard Unit Net /GrossWeight(kg)

12-13

30/32

30/32

Long-run unit Net /GrossWeight(kg)

7-8

15/17

15/17

Operating Environment

0-40°C

Relative Humidity

0-90%(non-condensing)

Altitude

<1500m.when>1500m,derating

Noise Level

<55db at 1 Meter

Interface

Smart RS-232;USB,Dry contact board,SNMP(independent to RS232)





Competitive Advantages:


1: Three Years' warranty for Online UPS, and 1% free UPS or 2% free PCB Boards
3: Good after-sales service, we will be full responsible for any faults caused by our side
4: Professional experience in power field more than 10 years
5: Professional technical support before and after sales

6: Timely response, fast delivery time and flexible operations to satisfy any customers' special requests.

7: Free OEM & ODM Service

8: Competitive price, quality and mature products
