Product Details:
Payment & Shipping Terms:
|
| Product Name: | Best Mono Solar Panel | Applicant: | Solar Power System For Familly |
|---|---|---|---|
| Size Of Panel: | 1480*680*40 | Solar Cells Style: | 156*156 |
| Solar Cells Array: | 4*9 Pcs | Max Output Power: | 150W |
| Standard: | CE/CSA/TUV | Grade: | A Grade |
| Weight: | 11.0Kg | ||
| High Light: | high efficiency solar panels,high power solar panels |
||
150 Watt Mono Solar Panel 1480 x 680 Yellow Color Frame Cell Germany
Features
Solar Power System
1, 150W Mono Solar Panels
2, High Efficiency Solar Cells
3, Competitive Price
4, 5 years warranty
Benefits
Manufactured in an ISO 9001:2000 certified plant
High efficiency , high safety , high reliability
Output power tolerance of +/-3%.
25 Years limited warranty on Power output.
3 Years limited warranty on materials and workmanship
Specification
|
Type |
150W |
|
Mono or Poly |
Mono |
|
Maximum power (Wp) |
150 |
|
Maximum Power voltage (V) |
18.0 |
|
Maximum Power current (A) |
8.34 |
|
Open circuit voltage (V) |
21.6 |
|
Short circuit current (A) |
9.09 |
|
Number of cells (Pcs) |
36 |
|
Size of module (mm) |
1480*680*40mm |
|
Temperature coefficients of Pm (%) |
-0.47%/℃ |
|
Temperature coefficients of Isc (%) |
-0.35%/℃ |
|
Temperature coefficients of Voc (%) |
0.05%/℃ |
|
Temperature Range |
-40℃-85℃ |
|
Tolerance Wattage (e.g. +/-5%) |
+3% |
|
Weight per piece (kg) |
11.0kg |
|
Module Efficiency (%) |
>15.36% |
|
Frame (Material, Corners, etc.) |
Aluminum |
|
Standard Test Conditions |
AM1.5 1000W/m2 25℃ |
|
|
mono solar panel, low price solar panel, solar panel module, solar pv module, mono crystalline silicon solar panel module, solar cell plate,solar sheet...
