Product Details:
Place of Origin: china
Brand Name: Tokpower equipment
Certification: CE , CCC , SAA , FCC ,UL
Model Number: TAP60 - xxxSyyy
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Packaging Details: inner package : white box ; outer package: carton ,
Delivery Time: 10 ~ 19 working days
Payment Terms: T/T
Supply Ability: 500,000pcs / Mon
Detailed Product Description
Input Voltage Range: AC90V ~ 264V , 47Hz ~ 63Hz Output Voltage Range: DC 5v 12V 24V
Output Current Range: 0.1A ~ 12.5A Max Output Power: 12W
AC Plug: US UK EU AU Output Mode: DC Cord
Case Color: Black Socket Type: Wall Mount
Materials: PC+ABS Warranty: 24months
Protection: OCP OVP OTP Services: High Quality After Sales Service
High Light:

power supply desktop

,

desktop pc power supply

Desktop Power Adapter 12v 4a AC DC Power Supply Circuit Electrical Transformer 48W

Desktop Power Adapter 12v 4a AC DC Power Supply Circuit Electrical Transformer 48W 0

Model

Input

Output





Frequency

Safety standard

Certification

Power

Voltage

Load





Vac / Freq

W(max)

Vdc

A(max)





TAP50-120S410U1

100~240VAC

50W

12V

4.26A

UL/EN60950
ITE/EN60601
EN61347
EN60065
EN61558

CE,CCC,
CB,GS,
FCC,
KC,SAA,
UL



47~63Hz











TAP50-190S260U1



50W

19V

2.63A





TAP50-240S200U1



50W

24V

2.08A





TAP50-360S0130U1



50W

36V

1.39A





TAP50-480S100U1



50W

48V

1.40A









INPUT

 ENVIROMENTAL


Input voltage range        90-264Vac


Operating temperature       0 to 40℃


Input frequency            47-63Hz


Operating humidity          20% to 95%


Inrush current             60A MAX


Storage temperature         20 to 80℃


Standby power              0.3W MAX


storage humidity           5% to 95%

 OUTPUT

 Certification Approval


Output voltage range        +-5%

CB GS KC CCC PSE CE UL


Turn on delay time          2s Max




Efficiency level               V

 Meet safety and EMC standard


Over current protection    fault remove auto recovery

Safety
IEC/EN 61558 1     IEC/EN 61558 2 16


Over voltage protection    fault remove auto recovery

EMC
EN55022  EN55024


Short circuit protection    fault remove auto recovery



Certificates listed are for reference only .  Please contact our sales representative for details

Description:
1.   input voltage range of AC90-264V. wide voltage input, comply with the global standard.
2.   input voltage frequency: 47-63Hz
3.   output voltage: according to customer requirements
4.   output voltage adjustable rate: 1%
5.   rated output current can be customized
6.   current output range 0-5A
7.   Output Ripple & noise less than 100mVp-p. DC ripple small, high efficiency,low temperature, long service life,
8.   the working efficiency low power design of 78-86%. no-load power consumption is less than 0.3W
9.   output short circuit protection. The built-in over current, over voltage protection(auto recovery)
10.   working temperature 0 °C ~+50 °C
11.   storage temperature -20 °C ~+85 °C

Applications:

It’s suitable for an extremely wide range of applications, including:
LED, CCTV camera;
Communications and security products;
LED Strip Lighting/ LED lamp / LED Light, LED / LCD display. security systems, instrumentation, medical equipment, audio-visual products, digital products, LED lighting, electric cars and other products

Competitive Advantage:

1.With high efficiency, low loss, environmental protection circuit design; with over voltage protection, overload protection;
2.Products beautiful, high-temperature flame-retardant shell by ultrasonic welding, safety and reliability;
3.Output interference is very small, the output voltage stability, better able to extend the life of an external electric;
