0STI 500W pv inverter DC-AC, DC/AC inverter

China 0STI 500W pv inverter DC-AC, DC/AC inverter supplier

Large Image :  0STI 500W pv inverter DC-AC, DC/AC inverter

Product Details:

Place of Origin: Guangdong
Brand Name: Jinghongkai
Certification: CE, RoHS, ISO9001, ISO14001
Model Number: STI 500-24-220

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: 180USD
Packaging Details: Standard Export Wooden Package.
Delivery Time: 7-15 working days for sample, 15-20 working days once received deposit
Payment Terms: 30% First payment,70% D/P
Supply Ability: 5000PC/Months
Contact Now
Detailed Product Description

STI 300W power inverter DC-AC, DC/AC inverter

STI series is a sine wave power frequency inverter which can convert 12V/24V/48Vdc to 220V/230V 50Hz based on full digital and intelligent design. It features high reliability, high efficiency, concise outline, full protection functions, easy installation and operation. The inverter can be applied in many fields especially for solar photovoltaic power system.

0STI 500W pv inverter DC-AC, DC/AC inverter0STI 500W pv inverter DC-AC, DC/AC inverter0STI 500W pv inverter DC-AC, DC/AC inverter0STI 500W pv inverter DC-AC, DC/AC inverter

Feather:

  • Complete isolation-type inverter technology, noiseless output
  • Adoption of advanced SPWM technology, pure sine wave output
  • Dynamic current loop control technology to ensure inverter reliable operation.
  • Wide DC input voltage range
  • Excellent EMC design
  • Low output harmonic distortion(THD≤3%)
  • LED indicators display input voltage range, load power range, normal output & failure state
  • Optional energy saving mode
  • Wide working temperature range (industrial level)
  • Continuous operation at full power

PRODUCT FAMILY

STI200/STI300/STI500/STI700/STI1000

12V/24V/48V

200W,300W,500W,700W,1000W

ELECTRONIC PROTECTIONS

  • Output Short Circuit protection
  • Overload protection
  • Input reverse polarity protection
  • Input low voltage protection
  • Input over voltage protection
  • Inverter abnormal protection
  • Overheating protection

Application

Output socket(option)

Universal European Australia/New Zealand

STI series

www.jhk-power.com

TECHNICAL SPECIFICATIONS

Model

STI200-12-220

STI200-24-220

STI300-12-220

STI300-24-220

STI500-12-220

STI500-24-220

STI700-24-220

STI1000-24-220

STI1000-48-220

STI200-12-230

STI200-24-230

STI300-12-230

STI300-24-230

STI500-12-230

STI500-24-230

STI700-24-230

STI1000-24-230

STI1000-48-230

Nominal Battery Voltage

12V

24V

12V

24V

12V

24V

24V

24V

48V

Input voltage range

10.5~

16VDC

21~

32VDC

10.5~

16VDC

21~

32VDC

10.5~

16VDC

21~

32VDC

21~

32VDC

21~

32VDC

42~

64V

Consumption NO Load(ON)

≤4W

≤5W

≤5W

≤6W

≤5W

≤6W

≤8.5W

≤10W

≤12W

Output Voltage

AC220/230V±3%

Continuous Power

200VA

300VA

500VA

700VA

1000VA

Power 10 sec

300VA

450VA

750VA

1050VA

1500VA

Power 1.5 sec

400VA

600VA

1000VA

1400VA

2000VA

Surge Power

640VA

960VA

1600VA

2240VA

3200VA

Output Mode

Single Phase

Wave Form

Pure Sine Wave

Frequency

50Hz±0.2%

Distortion THD ( resistive load)

≤3%

≤2%

≤3%

≤2%

≤5%

≤2%

≤3%

≤3%

≤2%

Efficiency at Rated Power

≥81%

≥85%

≥81%

≥87%

≥81%

≥87%

≥87%

≥87%

≥89%

Max. Efficiency

≥88%

≥89%

≥90%

≥91%

≥91%

≥93%

≥93%

≥93%

≥94%

Dimensions(mm)

315×166×101

325×187×112

335×232×123.3

373×232×123.3

Net Weight

4.5kg

5.3kg

7.3kg

9.4kg

11.8kg

Working Temperature

-20℃~ +50℃

※Technical data at 25℃.

MT

All product specifications are subject to change without notice.
