Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass

Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass
Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass

Large Image :  Film - removing Glass Edging Machine Double Edger For Refrigerator Shelf Glass

Product Details:
Place of Origin: China
Brand Name: PuYu
Certification: CE
Model Number: YEPC6M1300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Packed in wooden case for outer packing or stretch film packing.
Delivery Time: 45 working days after received your payment
Payment Terms: L/C, T/T
Supply Ability: 10 sets per month
Detailed Product Description
Product Name: Appliance Glass Edging Machine , Glass Double Edger For Refrigerator Shelf Glass Application: Refrigerator Shelf Glass Deep Processing Industry
Glass Maximum Size: 1300 Mm Glass Minimum Size: 150×150 Mm
Glass Thickness: 2-12 Mm Speed: 3-10 M/min
Standard: CE Motor/Spindle: 3+3
High Light:

glass edge grinding machine

,

glass processing machines

Appliance Glass Edging Machine , Glass Double Edger For Refrigerator Shelf Glass





Specifications:



Model

YEPC6M1300

YEPC6M1600

YEPC6M2000

YEPC6M2500

Max. Width of Glass

1300mm

1600mm

2000mm

2500mm

Min. Size of Glass

120*120mm

120*120mm

120*120mm

120*120mm

Table Height

900-950mm

900-950mm

900-950mm

900-950mm

Glass Thickness

3-12mm

3-12mm

3-12mm

3-12mm

Speed

3-8 m/min

3-8 m/min

3-8 m/min

3-8 m/min

Parallelism Error

± 0.1mm/m

 ± 0.1 mm/m

 ± 0.1 mm/m

 ± 0.1 mm/m

Diagonal Error

± 0.3 mm/m

 ± 0.3 mm/m

 ± 0.3 mm/m

 ± 0.3 mm/m

Total Power

23kw

23kw

23kw

23kw

Floor Space

3650*3070*1930mm

3650*3370*1930mm

3650*3770*1930mm

3650*4270*1930mm

Weight

5500kg

5800kg

6800kg

7800kg



Applications:



The Appliance Glass Edging Machine , Glass Double Edger For Refrigerator Shelf Glass is mainly used in

the flat refrigerator glass grinding and chamfer safety corner, such as solar glass, appliance glass, furniture glass and light glass etc. If it is used in the glass of high polishing requirements, increase the

quantity of spindles properly.





Description:



This Appliance Glass Edging Machine , Glass Double Edger For Refrigerator Shelf Glass for grinding

appliance flat glass, rough grinding, refine grinding the double straight line edges and chamfering safety corner, such as solar glass, furniture glass, light glass, refrigerator shelf glass, microwave oven glass panel, stove glass panel, Lampblack machine glass, Sterilizer (Disinfection Cabinet) etc.



1.Solid structure,accurate and smooth drive system, advanced control system and powerful processing

capability.

2.PLC touch screen control, variable frequency speed control, right angle positioning correction

configuration to guarantee the parallism and diagonal precision when grinding flat glass.

3.The main transmission adopts variable-frequency motors.



Competitive Advantage:



1. Main transmission shaft is placed on the upper of machine, which extends main shaft life and easy to

replace synchronous belt.

2. The design of catch pawl ensures the high precision of glass diagonal.

3. Unique design of grinding head that improves the running accuracy and impact resistance of the

grinding head and prolongs the service life of the motor.

4. The design of three-point lifting pillar ensures perfect straightness.

5. The upper design of down chamfering motor ensures the completeness of sliding table, and keeps

machine structure more stable.

6. Automatic lubricating system extends equipment life.



Available Type:

  1. Corner Dubbing
  2. Film-removing
  3. High Polishing Wheel





Appliance Glass Edging Machine , Glass Double Edger For Refrigerator Shelf Glass
