Product Details:
Payment & Shipping Terms:
|
| Panel Model: | LQ240BC9004 | Panel Brand: | CMO |
|---|---|---|---|
| Descrition: | A-Si TFT-LCD ,2.4 Inch, 240×320 | Panel Type: | A-Si TFT-LCD |
| High Light: | High sensitive delay,Time delay relay |
||
Panel Model |
LQ240BC9004 |
|---|---|
Panel Brand |
CMO |
Descrition |
a-Si TFT-LCD ,2.4 inch, 240×320 |
Panel Type |
a-Si TFT-LCD |
Operating Temperature |
-20 ~ 70 °C |
Storage Temperature |
-30 ~ 80 °C |
Dot Resolution |
240(RGB)×320 (QVGA) |
|---|---|
Pixel Configuration |
RGB Vertical Stripe |
Pixel Density |
166 PPI |
Aspect Ratio |
3:4 (H:V) |
Form Factor |
Flat Rectangle Display |
Dot Pitch |
0.051×0.153 mm (H×V) |
Pixel Pitch |
0.153×0.153 mm (H×V) |
Weight |
12g |
Active Area |
36.72×48.96 mm (H×V) |
Bezel Area |
39.62×51.82 mm (H×V) |
Outline Dimension |
42.92×60.18 mm (H×V) |
Outline Depth |
1.9±0.15 mm |
Landscape or Portrait |
Portrait type |
Touch Panel |
Without |
Display Mode |
TN, Normally White, Transmissive |
|---|---|
Brightness |
350 cd/m² (Typ.) |
Contrast Ratio |
300 : 1 (Typ.) (Transmissive) |
Display Color |
262K (6-bit) |
Color Gamut |
60% NTSC (CIE1931) |
Response Time |
20 (Typ.)(Tr+Td) |
Viewing Angle |
65/65/65/50 (Typ.)(CR≥10) (L/R/U/D) |
Viewing Direction |
12 o'clock |
White color Chromaticity |
Wx:0.300; Wy:0.330 |
Sunlight Readable |
N |
Vertical Frequency |
75Hz |
|---|---|
Reverse Scan |
No |
Lamp Position |
Edge light type |
|---|---|
Lamp Type |
WLED |
Lamp Amount |
1S4P |
Lamp Shape |
4 strings |
Lamp Current |
20mA (Typ.) |
Lamps Power Consumption |
280mW (Typ.) |
Interface Type |
Included in panel signal interface |
Lamp Driver Board |
No |
Signal Category |
CPU |
|---|---|
Signal Class |
CPU |
Input Voltage for Panel |
2.8V (Typ.) |
Panel Power Consumption |
13.0mW (Typ.) |
Interface Type |
Connector |
