TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva

China TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva supplier
TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva supplier TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva supplier TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva supplier TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva supplier

Large Image :  TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva

Product Details:

Place of Origin: China
Brand Name: PBP
Certification: CE,ISO
Model Number: TNS
Contact Now
Detailed Product Description


TNS Three Phase Automatic Voltage Regulator (AVR) 1kva - 15kva, 20kva - 90kva
TNS series three-phase separate regulated full automatic AC regulated power source is composed of three groups of SVC single -phase voltage stabilizer with “start –shutdown-connection. It has the function of over-voltage protection, delaying output,error protection,phase failure protection etc. It is suitable in the stabilizing electric supply and protection to any three-phase equipment as well as the overall stabilizing protection of power supply in small enterprise.
Applications:
It is suitable in industrial equipment and instruments,armarium,com-puter network,elevator and the overall regulated power supply in small enterprise

1-15kva

Specification of AVR

TNS-1.5KVA

TNS -3KVA

TNS -4.5KVA

TNS -6KVA

TNS -9KVA

TNS -15KVA

Input

Phase

Three phase

Voltage

AC260V-430V

Frequency

50Hz/60Hz

Output

Voltage

380V±3%

Capacity

1.2KW

2.4KW

3.6KW

4.8KW

7.2KW

12KW

Frequency

50Hz/60Hz

Protection

Low voltage

318V±7V

Over voltage

426V±7V

Over heat

Optional

Cooling system

Natural cooling system (Optional)

Short phase

YES

Time Delay

3-7sec/3-7min (Selectable)

Bypass

Auto/Manual (Optional)

Overload/short circuit

YES

Packaging

Pcs per Carton

1

Shipping Wt.(Kg)

15

18.3

18.75

31.5

38.9

89.75

Packing dimensions(mm)

530*370*205

380*390*795

450*490*940

Efficiency

AC-AC

>95%

Acoustic

Noise level

≤50dB

Environment

Temperature

-5℃ to 45℃

Humidity

20% to 90%

QTY(pcs)

20FT

700

700

700

238

238

135

20-90kva

Specification

TNS-20KVA

TNS-30KVA

TNS -45KVA

TNS -60KVA

TNS -75KVA

TNS -90KVA

Input

Phase

Three phase

Voltage

AC276V-430V

AC304V-456V

Frequency

50Hz/60Hz

Output

Voltage

380V±3%

Capacity

16KW

24KW

36KW

48KW

60KW

72KW

Frequency

50Hz/60Hz

Protection

Low voltage

318V±7V

Over voltage

426V±7V

Over heat

Optional

Cooling system

Natural cooling system (Optional)

Short phase

YES

Time Delay

3-7sec/3-7min (Selectable)

Bypass

Auto/Manual (Optional)

Overload/short circuit

YES

Packaging

Pcs per Carton

1

Shipping Wt.(Kg)

94.55

107.25

138.2

149.05

271.2

295

Packing dimensions(mm)

570*510*1055

675*655*1115

850*790*1530

Efficiency

AC-AC

>95%

Acoustic

Noise level

≤50dB

Environment

Temperature

-5℃ to 45℃

Humidity

20% to 90%

QTY(pcs)

20FT

90

90

20

20

14

14


Competitive Advantage:
(1) The AC voltage regulator has a large capacity & high precision
(2) Adopted compensated voltage technology
(3) Wide input voltage range
(4) Over voltage protection
(5) Output voltage three phase auto-balance (individual control)
(6) The AC voltage regulator is equipped with bypass system
(7) LCD/LED/Analog display are all available
(8 ) AVR is a necessary electronic device in electric power supply system.
