Product Details:
Payment & Shipping Terms:
|
| Product Name: | 600W Off-grid Home Solar Power System | Application: | Solar Generator |
|---|---|---|---|
| Quantity Of Panel: | 2 Pcs Or Optional | Quantity Of Inverter: | 1 |
| Power Of Inverter: | 600KW | Standard: | CE/CSA/TUV |
| Type: | Home Solar Power System | ||
| High Light: | off the grid solar power systems,off grid living solar power system |
||
Roof Installation Intelligent Power Generator 600W Off-grid Solar Power System
Descriptipon:
1. Modified sine wave output
2. Electricity - Battery automatic conversion
3. Different choice of input voltage range
4. High-frequency digital technology, MCU control, more stable capablity
5. High efficiency rate of DC - AC conversion, minimize energy loss
6. Tower design, can both stand up and lay down, can be placed flexibly
7. Ultra-load protection
8. Restoration of electricity, automatically activated
9. Offline-charging functions (when the utility comes to normal, even if it is not turned on, the machine can still charge the battery)
Specification:
| ITEM | SPECIFICATION: | ||
| SOLAR PANEL |
TYPE NO: | P7Y-300 | |
| QTY: | 2pcs | ||
| CONNECT ARRAY: | 2 series in parallel | ||
| SPEC: | CELLS: | 156mm polysilicon cells*72 | |
| Pm(Wp): | 300W | ||
| Vm(V): | 36V | ||
| Im(A): | 8.33A | ||
| Voc(V): | 44.8V | ||
| Isc(A): | 8.73A | ||
| size(MM): | 1956*992*45MM | ||
| N.W(KG): | 22.5KG | ||
| SOLAR BRACKET | Material: | Galvanized steel | |
| SPEC: | 1*2,suit for solar panels array | ||
| Install place: | ground or flat roof | ||
| POWER KIT |
TYPE NO: | CESC-KGP600 | |
| CONTROLLER: | Controller Mode: | PWM | |
| Solar panel input range: | DC30V-DC50V | ||
| Rated voltage of solar input: | DC36V | ||
| Floating charge voltage: | 27.6V | ||
| Charging voltage: | 24V DC | ||
| Charging current: | 30A | ||
| Efficiency: | 96% (Max) | ||
| INVERTER: | Rated Output Power: | 600W | |
| Peak power: | 200% * 1s | ||
| Working Efficiency: | >83% | ||
| Output Wave: | Pure Sine Wave(THD≤5%) | ||
| Output vltage: | 220V50HZ/110V60HZ | ||
| Grid power input: | 220V50HZ/110V60HZ | ||
| Switching Time: | ≤4 ms (between grid and inverter) | ||
| Protection Functions: | DC over-voltage protection/over-voltage self-revcovery | ||
| DC low-voltage protection/low-voltage self-revcovery | |||
| Overheat/short-current/overload protection | |||
| Features: | AVR Functions:AC145V-275V(input), AC198V-242V (output) |
||
| batteries can be charged by Grid and automatic supply power when Grid cut off | |||
| Size: | 355mm×175mm×210mm | ||
| N.W: | 10.8kg | ||
| BATTERY | Battery Type: | Maintain-free Lead-acid battery | |
| Capaticty: | 12V/65AH*2 (Max.:1560WH) | ||
| connect array: | 2pcs in series | ||
| system voltage: | 24V DC | ||
| N.W: | 20kg | ||
| OTHERS ACCESSORIES |
PV CABLE: |
SPEC&QTY: | 4mm sq with MC4 connectors: 30m |
| SPEC&QTY: | 25mm sq, 4m | ||
