Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom

China Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom supplier
Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom supplier Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom supplier Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom supplier Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom supplier

Large Image :  Powervalue 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom

Product Details:

Place of Origin: Shenzhen ,China
Brand Name: HRD/OEM/ODM
Certification: CE, ISO9001
Model Number: PV3110, PV3320,...., PV33200

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Price: negotiable
Packaging Details: 1PCS/1CARTON,wooden case
Delivery Time: 20days after down payment
Payment Terms: TT or LC at sight
Supply Ability: 100pcs/ month
Warranty: 2 years after shipment with 10years technical support
Contact Now
Detailed Product Description

Powervalue II 3 Phase Online Power Ups 10kva to 400kva DSP For Telecom


Introduction:
POWERVALUE II Online  LF  3/3phase large power UPS(10kVA-400kVA), offer advanced DSP control, high speed 32 bits digital IC, DDC control technology, also use advanced high power IGBT and SCR, it is a digital, Informationization, Networking, Online Intelligent Pure Sine-wave Uninterruptible Power Supply, which is based on reliable, advanced, high efficiency digital/analog hybrid technology. POWERVALUE II 3:3 phase  series can supply stable complete protection for your critical equipment.
Ideal Application:
Finance, Telecom, Insurance, Traffic, Taxation, Military, Security, Energy, Education, Government, Industry, etc..

Features&Benefits:

Pure sine wave output,true online double conversion

Output with isolation transformer
7 inch  touch screen with high resultion
Can be set to ECO mode
With EPO function
Can be with 100% unbalance load
Adopt the fourth layer PCB,and SMD technology
Sixth generation IGBT, much higher efficiency up to 95%, lower temperature, more reliable,
Full protection, overload, over voltage, short circuit, over temperature etc
Cold start
Generator compatible

EVENT LOG 256 LOGS

Advanced parallel function, with common battery, Maximum 8pcs;
With RS232 and RS485 standard collocate,
Option SMMP and dry contact connection
Option battery manage function



Model

PV3310

PV3320

PV3330

PV3340

PV3360

PV3380

PV33100

PV33120

PV33160

PV33200

Capacity

10Kva

20Kva

30Kva

40Kva

60Kva

80Kva

100Kva

120Kva

160Kva

200Kva

AC INPUT

Phase

3phase +N+G

Voltage

380VAC/400V±25% or 208v+/-25%

Frequency

50/60Hz±4hz(Line Mode),50/60Hz±0.1Hz(battery mode)

BYPASS INPUT

phase

3phase +N+G

Voltage

380VAC/400VAC or 208v (+/-15%)

Frequency

50Hz±5%,60Hz±5%

OUTPUT

Phase

3phase+N+G

Voltage

380VAC/400V or 208v±1%

Frequency

50/60Hz±10%,60Hz±10%

charging current

3A~30A settable(depend on battery capacity)

Battery

Max.discharge current(A)

28

56

85

113

169

225

282

338

450

560

Battery quantity

30/32pcs

battery voltage

360/384VDC(348-384V acceptable)

Floating voltage

410/432VDC

Charging
current

3A~30A(0.1C according to battery capacity)settable

Nominal voltage

                       380V/400VAC±1%(steady load),380V/400VAC±5%(load fluctuate)

Nominal frequency

50Hz±0.05%,60Hz±0.05%(battery supply power)

Frequency

<±0.05% (un Synchronization);<±2% (Synchronization)

Crest factor

3:1

Total harmonic distortion

Linearity load <3%;non-linearity load<5%

Dynamic load voltage transient

<±5%(from 0 to 100% abrupt change)

Moment restart time

<10ms

Balance load voltage

<±1%;<±5%(imbalance load voltage)

Overload capability

125% 1min,150% 1S

Efficiency

>82%(at 100% load)

Working temperature

0~40℃

Humidity

0%~90%(non~condensing)

Type of cooling

Forced draught

Noise dB

40~50(1m)

45~55(1 m)

55~60(1m)

60~65(1m)

Physical

Case color

Gray /black(option)

Input cable

The bottom / back

Dimension
W×D×H(mm)

600*620*1200

600*720*1460

950*820*1780

1380*850*1780

G .W(kg)

225

250

310

350

410

550

850

920

1320

1670

Input /output device

Terminal Block




All specification subject to change without further notice.
