4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase

China 4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase supplier
4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase supplier 4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase supplier 4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase supplier

Large Image :  4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase

Product Details:

Place of Origin: China
Brand Name: UPSEN
Certification: CE, ISO, RoHS
Model Number: Cosmos Star Series 1-6Kw

Payment & Shipping Terms:

Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Wooden Box
Delivery Time: 7-15 Days
Payment Terms: T/T, LC, WU, Money Gram etc
Supply Ability: 50,000pcs/Month
Contact Now
Detailed Product Description
Output Voltage (V): 220V / 230V/ 240V Input Voltage: 12/24/48VDC
MAX Ouput Current: 15A Frequency: 50HZ/60HZ
Transfer Time: 10ms

4000W / 5000W Solar Power Inverter With Pure Sine Wave And Single Phase

Model: Solar Inverter Controller All in one Cosmos Star Series 1000W-6000W (1ph in/1ph out)

Hybrid Inverter Overview
1 .  Pure sine wave inverter
2 .  Buit-in MPPT Solar mppt charger controller 20/30/40/50/60A
3 .  Cold start function
4 .  Compatible to mains Voltage or generator power
5 .  Auto restart while AC is recovering

Key Features:

1: Professional off grid solar system solution, which is a combination of big power inverter and solar controller
2: Wide input voltage range, single MPPT
3: More logical circuit arrangement, stricter production control and simpler structure design
4: Remote control & RS232 communication port
5: DIP switch optional: Selectable charging voltage for various battery type
6: Four stages smart charging, charging current adjusted automatically
7: Large graphic LCD display with support for multiple languagees
8: Manual control input&output breakers

9: AC Grid priority & battery priority working mode as selectable
10: AC grid mode: AC Bypass supplies load when AC is normal, battery invert AC supplies load when AC is off
11: Inbuilt MPPT Solar Charger Controller 20/30/40/50/60A, AC Charger 35 - 70A, with DC Voltage 12/24/48VDC
12: LCD&LED Screen for option
13: Pure sine wave output which matches wave form of AC grid no matter is on AC grid mode or inverter mode, workable on inductive load
14. Selectable input voltage range for home appliances and personal computers
15. Monitoring software for real time status display and control


Technical Specification


Mode NO.

CS600

CS1000

CS2000

CS3000

CS4000

CS5000

CS6000

Rated Power

600W

1000W

2000W

3000W

4000W

5000W

6000W

AC INPUT

Phase&Waveform

                                                    Single pahse&Pure Sine Wave

Voltage

                                             110VAC/120VAC/220VAC/230VAC/240VAC

Fequency

                                                       50HZ/60HZ(Auto adjust)

Voltage range

                                                       95-127VAC/194-253VAC

Frequency range

                                                          48-54HZ/58-64HZ

AC Output

Waveform

                                                Pure Sine wave and single phase

Voltage

                                         110VAC/120VAC/220VAC/230VAC/240VAC

Frequency

                                                                 50HZ/60HZ

Peak Power

1800W

3000W

6000W

9000W

12000W

15000W

18000W

Battery


Battery DC

12/24VDC

12/24VDC

          12/24/48VDC

                    24/48VDC

MAX charging cunrrent

                                                                             20A-75A

Battery type

                                                            GEL,AGM,Sealed lead acid

MPPT Controller


PV Input

                                                    15-30VDC For 12VDC/30-55VDC For 24VDC

MAX charging cunrrent

                                                                      20/30/40/50/60AMP

MAX Ouput current

                                                                15A

for DC laod

Transfer efficiency


MPPT efficiency

                                                  more than 95%

Line Mode

                                                   more than 95%

Battery Mode

                                                    more than 85%

Power Saver

                                            Available when load is less than 50A

Transfer time

                                                            10ms

Indicator


7-LED Indicators

Left to right:1.Line Mode(Green),2.Inverter Mode(Green),Charging Mode(Yellow),4.Full Charged(Green),

5.Over Temp(Red),6.Over Load(Red),7.Saving Mode(Green)

2-LED Indicators on MPPT

Power/CHG Mode

Dimension

486*400*181mm

486*432*181mm

Weight

22KG

26KG

28KG

33KG

45KG

52KG

56KG




Competitive Advantages:

1: Three Years' warranty for pure sinewave inverter, and 1% free set or 2% free PCB Boards
2: Good after-sales service, we will be full responsible for any faults caused by our side
3: Professional experience in power field more than 10 years
4: Professional technical support before and after sales
5: Timely response, fast delivery time and flexible operations to satisfy any customers' special requests.
6: Free OEM & ODM Service
7: Competitive price, quality and mature products
