high power 600W off grid Solar Power System with Pure sine wave output

China high power 600W off grid Solar Power System with Pure sine wave output supplier

Large Image :  high power 600W off grid Solar Power System with Pure sine wave output

Product Details:

Place of Origin: China
Brand Name: Sunuse
Certification: CE, ROHS
Model Number: H600

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: negotiation
Packaging Details: Using Doublewall Corrugated Fiberboard to do package which ensure well protected. Also we can do the package per your request
Delivery Time: 3-7 working days for sample, about 10-20 working days for bulk
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal, Escrow, E-Credit Line
Supply Ability: 3000pcs/month
Contact Now
Detailed Product Description
Solar Panel ( Monocrystalline ): 18.4V/150Wx4 (600W) Maintenance Free Lead-acid Battery: 12V/150AHx2 (300AH)
Solar Controller: 24V/30A Host Output Voltage: DC Output:12V/20A (Max.), AC Output:220V/800W (Pure Sine Wave)



high power 600W off grid solar power system for home with Pure sine wave output





Quick Detail:

>> All-in-one high integrated off-grid solar system
>> Pure sine wave output
>> Battery power indicate
>> Digital indication for PV charging & load power
>> Automatic switch between PV generation and utility power
>> PV power generation always preferred
>> High-efficiency, easy-installation and reliable performance
>> Economic and environment-friendly





Specification:



Model:H600

Item

Configuration Name

Configuration Parameters

1

Solar panel ( monocrystalline )

18.4V/150Wx4 (600W)

Maintenance free Lead-acid Battery

12V/150AHx2 (300AH)

Solar Controller

24V/30A

Host Output voltage

DC output:12V/20A (Max.)

Number of Ports:2

AC Output:220V/800W (Pure sine wave)

Number of Ports:4

Charge way(Mains complementary function)

Solar panel

AC 220V or Generator,   AC Charging current:20A

Host size

750*410*860mm

Host Weight

132kg

Load electricity Reference Table

No.

Load Name

Power(W)

Quantity (pcs)

Work time(H)

1

Led Lamp

5W

4

       8

2

16"  fan

15W

2

       8

3

21"   LED  TV

40W

1

       6

4

Portable Computer

70W

1

       6

5

Rice cooker  (3L)

300W

1

      1.2

6

Solar Pump

144W

1

       2

7

Total power

Storage capacity equivalent to 1.7 degrees every day .

Note: The above battery with a fully charged calculated by using the case of an ambient temperature of 25 ° C (77 ° F).





Application:


H600W solar home system is specially designed to satisfy with the electricity needs of small houses, as to produce and power some basic house loads,like lamp, fan, TV, radio etc., which brings you with a perfect turnkey solution by exploiting energy in a maximum, and meanwhile, save your electricity bill, average daily electricity output could reach to 1.0~2.0kwh.

Uninterrupted PV Power System is an all-in-one machine which includes solar inverter, solar battery, charge controller, battery cabinet and solar modules. The system can be applied to areas without grid-power network, villas, remote villages, island, no power supply areas and backup power for general families. Pure sine wave AC output 110V/220V/230V, 50Hz/60Hz.




high power 600W off grid Solar Power System with Pure sine wave output




FAQ:

1. Q: Do u have your own factory?
A: Yes, we have. Our factory located in Wenzhou city, Zhejiang province, China .

2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will arrange time to pick you up.

3. Q: Could u print our company LOGO on the nameplate and package.
A: Yes, we accept OEM orders.

4. Q: Do u have solar project engineer who can guide me to install system?
A: Yes, we have a professional engineers team. They can teach you how to install a solar system.
