LPS Desktop Power Adapter 75W / AC DC Switching Power Supply Adapter 12V 6A

Certification
China CHINA UPS Electronics Co., Ltd. certification
China CHINA UPS Electronics Co., Ltd. certification
The company considerate after-sales service ,And try their best to meet the requirement of customers. We will be a long-term cooperation.

—— Albert

This is a fantastic sourcing platform, considerate service and good quality product.

—— philip

You always can give me the best plan ,and it lets my customer feel great,i hope we can have another chance to cooperation.

—— Tim

I'm Online Chat Now

LPS Desktop Power Adapter 75W / AC DC Switching Power Supply Adapter 12V 6A

LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A
LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A

Large Image :  LPS Desktop Power Adapter 75W / AC DC Switching Power Supply Adapter 12V 6A

Product Details:
Place of Origin: china
Brand Name: Tokpower equipment
Certification: CE , CCC , SAA , FCC ,UL
Model Number: TAP75- xxxSyyy
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: USD1~ 3 / PC
Packaging Details: inner package : white box ; outer package: carton ,
Delivery Time: 10 ~ 19 working days
Payment Terms: T/T
Supply Ability: 500,000pcs / Mon
Detailed Product Description
Input Voltage Range: AC90V ~ 264V , 47Hz ~ 63Hz Output Voltage Range: DC 5v 12V 24V
Output Current Range: 0.1A ~ 12.5A Max Output Power: 75W
AC Plug: US UK EU AU Output Mode: DC Cord
Case Color: Black Socket Type: Desktop
Materials: PC+ABS Warranty: 24months
Protection: OCP OVP OTP Services: High Quality After Sales Service
High Light:

power supply desktop

,

desktop pc power supply

 LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A









Model

Input

Output





Frequency

Safety standard

Certification

Power

Voltage

Load





Vac / Freq

W(max)

Vdc

A(max)





TAP75-120S620U1

100~240VAC

47~63Hz

75W

12V

6.25A

UL/EN60950
ITE/EN60601
EN61347
EN60065
EN61558

CE,CCC,
CB,GS,
FCC,
KC,SAA,
UL

TAP75-190S400U1

75W

19V

3.95A

TAP75-240S310U1

75W

24V

3.12A

TAP75-360S200U1

75W

36V

2.08A

TAP75-480S150U1

75W

48V

1.56A



 LPS Desktop Power Adapter 75W  / AC DC Switching Power Supply Adapter 12V 6A 0

75W series external wall-mount AC/DC Adapter 12V6A switching power adapter (AC/DC adapter), class II, LPS, Universal input.
*Customized designs are available

*Reliability:
     100% full loading, 40°C, 4 hours each part of this series can be sold separately
     MTBF: meet MIL-HDBK-217F over 50,000 hours, full loading, 25°C burn-in
     Leakage current: 0.25mA, maximum at 264V AC
     Withstanding voltage: 3kV, 1 minute, 10mA (maximum), between primary and secondary
*Protection:
    Over-voltage protection
    Over-current Protection
    Short-circuit protection
    Thermal shutdown capability
*Humidity:
    Operating: 10 to 95% RH
    Storage: 10 to 95% RH
*Temperature:
    Storage: -20 to 65°C
    Operating: 0 to 40°C
*Emission and immunity:
    EN 55024/A1:2001
    CISPR 22 class B
    FCC part 15 class B
    CNS 13438 class B
    EN 55022 class B
    AS/NZS 3548 and AS/NZS 4251.1 class B
    IEC61000-4-2/3/4/5/6/11
    GB 9254-1998/GB 17625.1-2003
*Features:
    LED light indicator
    High Quality Competitive Price
    High-reliability
    High-efficiency consumption
    Light and portable ,convenient to carry , easy to use
    With fuse, short-circuit protection
    Environmently friendly, energy-saving, complying with the safe certification standard
    Double insulated circuit board designed to protect your valuable gadgets from short circuit
*Certifications:
    AS/NZS 60950:2000 and AS/NZS 60065
    UL 60950 and GB 4943-2001
    PSE IEC 60950 and EN60065
    CE (low-voltage directive)
    EN 60950:2009 and EN 60065
    Standards: US Energy Star, CEC, AS, MEPS, EUP and ErP
*Input Specifications:
    Inpout Voltage: 100 to 240V AC
    Input frequency range: 50 and 60Hz
    No loading power: 0.3W (240V AC)
    Current:300mA (maximum)
    Inrush current (240V AC): 25A, cold 25°C
    Efficiency: Conform to Level V (CEC/ERP/MEPS)
    Plug type: wall mount
*Output Specifications:
    Output power: 12W Max
    DC voltage: 5-30V DC,
    Output current: 0.1-2A
    Regulation: Line: ±1%, Load: ±5%
    Ripple and noise:100mV max
    Voltage precision: 5%

    Normal wire length: 1.5m ,1.8m , 2.0m
    DC Plug Specification:5.5*2.5,5.5*2.1,3.5*1.35
*application :
    LED display, led strip, nixie tube, street light, lamp
    Electrical equipment, Instrumentation
    Digital and electronic products
    LCD, LED, CCTV camera
    Building lighting decoration
    Communications and security products
