1KW Pure Sine Wave Grid Tie DC-AC Inverter

Name: 1KW Pure Sine Wave Grid Tie DC-AC Inverter
Brand: 1KW Pure Sine Wave Grid Tie DC-AC Inverter
SKU: 1KW Pure Sine Wave Grid Tie DC-AC Inverter
Price: 1 USD
Availability: InStock
Rating: 4.6 (170 reviews)

Large Image : 1KW Pure Sine Wave Grid Tie DC-AC Inverter

Product Details:

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece/Pieces
Packaging Details:	Foam pack for each inverter. Anti vibration. Export standard packing in cartons. or on pallets
Delivery Time:	3 days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	30000 Piece/Pieces per Month

Contact Now

Detailed Product Description

DC-AC Inverter
1.Exported to Europe, Australia, South America ect
2. VDE Certificate in process
3. 15VDC-60VDC input also OK

1KW Pure Sine Wave Grid Tie DC-AC Inverter

I. Feature:
- Generates pure Sine Wave
-Automatic power adjustment
- Constant Power Output
- Low distortion output on all ranges
- Allow different Power factor from loads
- Compact and light weight design
- Maximum Power Point Tracking (MPPT) - optimize power output
- Plug and Play Design, simply plug into an outlet (GFI), no hard-wiring
- Stackable (connect in parallel for higher output)
- Aluminum enclosure will act as heat sink to help dissipate heat
- Simple and safe installation
- Island protection: Inverter will shut down during black outs.
- Grid-Tied - sell green power directly back to the grid at a premium rate
(depends on your location)

II.Electrical Specifications - Output:

	Mode	1000W
	AC Output Power	1000W
	Maximum AC Output Power	90~140V 190~260V
	Frequency	45Hz~53Hz/55Hz~63Hz
	Total Harmonic Distortion (THD)	<;;5%
	Power Factor	0.93~0.99
	Island Protection	Yes, inverter shuts down during black out
	Output Current waveform	Pure Sine Wave

Electrical Specifications - Input:

	DC Input Voltage (Solar & Wind)	10.5V~28V
	Peak inverter efficiency	86~94%
	Over-current protection	105A
	Reverse Polarity Protection	Fuse
	Power consumption (Standby)	<;;1W
	Stackable	Unlimited as long as it doesn't exceed main circuit amperage limit

III.Mechanical Specifications:

	Operating temperature range	-20°C - 65°C
	Weight	2.3kg
	Dimension (L x W x H)	30 x 16.5 x5.5cm
	Mounting	Wall Mount at base
	AC Cable Length	1.8m
	Cooling	Convection cooled with fan
	Display	1 Red and 1 Green LED

IV.Application:

Install in a low humidity and well-ventilated area. Remove All flammable objects.
Connect the inverter to a wall socket with the supplied AC Power Cord
Connect the Solar Panel, Battery or Wind Turbine's DC Supply cables to the DC input
Terminal of the inverter. Wind Turbine installations will require respective charge
Controllers and dump loads

V.More Pictures of the 1000W grid tie inverter.
