220V 10KW Stand Alone Off Grid Solar Power Systems without Power Grid

Large Image : 220V 10KW Stand Alone Off Grid Solar Power Systems without Power Grid

Product Details:

Place of Origin:	China
Brand Name:	Zocen Solar
Certification:	CE, ISO9001
Model Number:	ZCOG-10000

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiation
Packaging Details:	1pc/carton
Delivery Time:	10-15 days
Payment Terms:	Ex works
Supply Ability:	500pcs/day

Contact Now

Detailed Product Description

Highlight:	residential solar power system

220V 10KW Stand Alone Off Grid Solar Power Systems without Power Grid

1> Quick Details

Solar System Type	110-240V AC Off Grid System	Backup time	3 days
Daily power consumption	28KWH-35KWH	System Voltage	220V AC
Inverter	Pure sine wave 10KVA	Solar Panels	298V/10000W
Battery	220V800AH AGM battery	Controller	DC 220V/50A
Distribution Box	with inverter and controller in	Battery Rack	with all batteries in

2> Description:

No noise or smells, solar operates totally silent
With no fuel consumption, no co2 emission, no air pollution. It's a clean, renewable energy source.
Easy to install and maintenance free.
System can be used for everywhere once there's sunshine. Ideal for remote locations that cannot be tied to the grid
Digital display screen which make output current and voltage visiable, malfunction can be detecated.
Microprocessor intelligent controller functioned with temperature compensation, automatic adjustment of charge and discharge parameters to improve battery life, with over charge, over discharge, overload, short circuit auto protection
110V/220V AC pure sine wave inverter with low distortion of output wave(less than 3%), various of loads available.
More than 20 years lifespan for solar panel and 8 years for the maintenance free lead-acid battery.
Standard structure of solar panel makes installation and transportation easier.

3> Application:

Lamps/TV/Fans/Video/Charger/MP3/MP4/Audio/PSP
Computer/Printer/Copier/Scanner/Screen//Fax
Microwave/fridge freezer/refrigerator/Coffee machine/Washing machine/Baker/Juice machine
Air conditioner/Water pump, etc

220V 10KW Stand Alone Off Grid Solar Power Systems without Power Grid 0
4> Technical data

Item No		ZCOG-10KW
Capacity		10KVA
System voltage		220VDC
Best output power everyday	Solar Radiation(kWh/m²/d):	28000WH
	Solar Radiation(kWh/m²/d): 5	35000WH
	Solar Radiation(kWh/m²/d): 6	42000WH
Inverter	Output wave	Pure sine wave
	Output voltage	AC110/220V
	Output frequency	50/60HZ
	Capacity	10000VA
	Precision of output voltage	±3%
	Precision of output frequency	±0.1%
	False output wave of AC	<3%
	Overload ability	120%, 60 seconds
	Invert efficiency	>85%
Solar Panel	Pmax	10000
	Vmp	298V
	Imp	30.92A
	Unit Size(LWH mm)	164099240
	Unit Weight(kg)	19.5
	Quantity	40
Battery	Capacity	220V800AH
	Unit Size(LWH mm)	412175342
	Unit Weight(kg)	53
	Quantity	110
Controller	Rated voltage	DC 220V
	Rated current	50A
	Control mode	PWM
	Protection	Reverse polarity, overload, reverse charge, etc.
Distribution Box		with inverter and controller in
Battery Rack		with all batteries in
Solar Mounting System		Pitch Roof/Flat Roof/Ground Mounting Type
